Instruction Manual CON 11/110
6
3.2 Conductivity Electrode Information
Your meter includes a conductivity electrode (Part No: EC-
CONSEN91W/ 35608-50) Ultem / Stainless Steel electrodes with
an electrode constant of K = 1.0. This conductivity / TDS electrode
features a built-in temperature sensor for Automatic Temperature
Compensation (ATC). It has a specially designed housing that
provides fast temperature response and reduces air bubble
entrapment, which makes it easy to obtain accurate, stable
readings.
Wetted parts include:
1. Polyetherimide PEI (Ultem ® )
2. Polybutylene Terephthalate PBT (Valox ® )
3. Stainless Steel (SS 304)
Proper use of electrode is essential to ensure that the optimum
measurement is taken in a short time.
The removable protective plastic electrode guard is meant for
simple periodic maintenance and it must be kept in tact during
measurement and calibration.
Always immerse the electrode beyond upper steel band.
NOTE:
1. DO NOT remove the protective electrode guard during measurement and
calibration as it may affect your readings.
2. We recommend that you do not submerge the electrode above the protective
yellow cap. You can submerge the cable for brief periods of time, but not
continuously.
Figure 6: Electrode immersion level
Figure 5: Conductivity
Electrode (EC-CONSEN91W/
35608-50)
