KROHNE IFC 090 Converter EN User Manual

Page 2

0/1

Contents

System description

0/4

Product liability and waranty

0/4

CE / EMC / Standards / Approvals

0/4

Items included with supply

0/4

Part A

System installation and start-up

1/1-3/2

Electrical connection: power supply

1/1-1/6

1.1

Location and important installation notes – PLEASE NOTE !

1/1

1.2

Connection to power

1/2

1.3

Electrical connection of separate primary head (F Version)

1/3-1/6

1.3.1

General information on signal cable A and field current cable C

1/3

1.3.2

Stripping (preparation) of signal converter

1/3

1.3.3

Grounding of primary head

1/4

1.3.4

Cable length (max. distance between signal converter and primary head)

1/5

1.3.5

Connection diagrams I and II (power supply, converter and primary head)

1/6

Electrical connection of outputs and inputs

2/1-2/6

2.1

Combinations of outputs and inputs

2/1

2.2

Current output I

2/1

2.3

Pulse output B1 (terminals B1 / B

⊥

)

2/2

2.4

Status outputs B1 and B2 (terminals B1 / B

⊥

and B2 / B

⊥

)

2/3

2.5

Control inputs B1 and B2 (terminals B1 / B

⊥

and B2 / B

⊥

)

2/4

2.6

Connection diagrams for outputs and inputs

2/5-2/6

3. Start-up

3/1-3/2

3.1

Switch-on and measurement

3/1

3.2

Factory settings

3/2

Part B

IFC 090

/ D Signal converter

4/1-5/14

Operation of the signal converter

4/1-4/12

4.1

Krohne operator control concept

4/1

4.2

Operating and check elements

4/2

4.3

Function of keys

4/3-4/4

4.4

Table of settable functions

4/5-4/9

4.5

Error messages in measuring mode

4/10

4.6

Reset totalizer and cancel error messages, RESET/QUIT menu

4/11

4.7

Examples of setting the signal converter

4/12

Description of functions

5/1-5/14

5.1

Full-scale range Q

100%

5/1

5.2

Time constant

5/1

5.3

Low-flow cutoff

5/2

5.4

Display

5/2-5/3

5.5

Internal electronic totalizer

5/3

5.6

Current output I

5/4

5.7

Pulse output B1

5/5-5/6

5.8

Status outputs B1 and B2

5/7

5.9

Control inputs B1 and B2

5/8

5.10

Language

5/8

5.11

Entry code

5/8

5.12

Primary head

5/9

5.13

User-defined unit

5/10

5.14

F/R mode, forward/reverse flow measurement

5/11

5.15

Characteristic of outputs

5/11

5.16

Combinations of binary outputs and inputs

5/12

5.17

Limit switches

5/12

5.18

Automatic range change BA

5/13

5.19

Applications

5/14
