Installation and operating instructions IFC 020
10.4 IFC 020 and ZD dimensions and weights
IFC 020 F
weight approx. 3.8 kg / 8.4 lb
10/5
dia. 9
(0.35”)
27.5
(1.08”)
1 output cable (see Sect. 2.4)
2 signal cable of primary head
(see Sect. 1.3)
3 field power cable of primary head
(see Sect. 1.3)
4 power supply cable (see Sect. 1.2)
5 internal connection
(see Fig. in Sect. 8.8, plug connectors
X3 and X5)
116 (4.57”)
160 (6.30”)
144 (5.67”)
9 (0.35”)
dia. 9 (0.35”)
4
5 258 (10.16”)
220 (8.66”)
1 2
3
4
34 (1.34”)
120 (4.72”)
1
1
ZD Intermediate
connection box
Weight approx.
0.5 kg/1.1 lbs
dimensions in mm
(--) dimensions in inch
PG 16
1 /
2
” NPT
57 (4.02”) 22 (4.02”)
80
125 (4.92”)
68 (2.68”)
(3.15”)
