Installation and operating instructions IFC 020
5/10
User-defined unit 5.12
Fct. 3.05 USER UNIT
Press
→
key.
→
TEXT VOL = set text for user-defined unit, press
→
key
• Liter
(max. 5 characters, factory-set: “Liter” or “US MGal”)
Characters assignable to each place: A-Z, a-z, 0-9, or “–” (= blank character)
Change flashing place (cursor) using
↑
or
↓
key.
Use
→
or
←
key to shift cursor 1 place to right or left.
Transfer to subfunction “FACT. VOL.” with
↵
key.
→
FACT. VOL. = set factor F
M
for volume, press
→
key
• 1.00000 E+3
(factory-set: “1000 or 2.64172 x 10
-4
” / factor F
M
= volume per 1 m
3
)
Setting range: 1.00000 E-9 to 9.99999 E+9 ( = 10
-9
to 10
+9
)
Change flashing place (cursor) using
↑
or
↓
key..
Use
→
or
←
key to shift cursor 1 place to right or left.
Transfer to subfunction “TEXT TIME” with
↵
key.
→
TEXT TIME = set text for required time, press
→
key
• hr
(max. 3 places, factory-set: “hr = hour”)
Characters assignable to each place: A-Z, a-z, 0-9, or “–” (= blank character)
Change flashing place (cursor) using
↑
or
↓
key.
Use
→
or
←
key to shift cursor 1 place to right or left.
Transfer to subfunction “FACT. TIME” with
↵
key.
→
FACT. TIME = set factor F
T
for time, press
→
key
• 3.60000 E+3
(factory-set: “3600” for hour or “8.64 x 10
4
” for day / set factor F
T
in seconds)
Setting range: 1.00000 E-9 to 9.99999 E+9 ( = 10
-9
to 10
+9
)
Change flashing place (cursor) using
↑
or
↓
key.
Use
→
or
←
key to shift cursor 1 place to right or left.
Press
↵
key to return to Fct. 3.05 USER UNIT.
Factors for volume F
M
(factor F
M
= volume per 1 m
3
)
Volumetric unit
Text examples Factor F
M
Setting
Cubic metres
m3
1.0
1.00000 E+0
Litres
Liter
1 000
1.00000 E+3
Hectolitres
h Lit
10
1.00000 E+1
Decilitres
d Lit
10 000
1.00000 E+4
Centilitres
c Lit
100 000
1.00000 E+5
Millilitres
m Lit
1 000 000
1.00000 E+6
US gallons
USGal
264.172
2.64172 E+2
Millions US gallons
USMG
0.000264172 2.64172 E -4
Imperial gallons
GBGal
219.969
2.19969 E+2
Mega imperial gallons
GBMG
0.000219969 2.19969 E -4
Cubic feet
Feet3
35.3146
3.53146 E+1
Cubic inches
inch3
61 024.0
6.10240 E+4
US barrels liquid
US BaL
6.28982
6.28982 E+0
US barrels ounces
US BaO
33 813.5
3.38135 E+4
Factors for time F
T
(factor F
T
in seconds)
Time unit
Text examples Factor F
T
(seconds)
Setting
Seconds
Sec
1
1.00000 E+0
Minutes
min
60
6.00000 E+1
Hours
hr
3 600
3.60000 E+3
Day
DAY
86 400
8.64000 E+4
Year (= 365 days)
YR
31 536 000
3.15360 E+7
