Installation and operating instructions IFC 020
5/6
→ VALUE P = set pulse value per unit volume
(appears only when “PULSE/VOL.” set under “SELECT P”, press → key.
• XXXX PulS/m3
• XXXX PulS/Liter
• XXXX PulS/US.Gal
• XXXX PulS/ user unit, factory-set: “Liter” or “US MGal”, see Sect. 5.12.
Select using ↑ or ↓ key.
Transfer to number setting with → key. 1st digit (cursor) flashes.
Set numerical value
• XXXX (setting range depends on pulse width and
full-scale range: P
min
= F
min
/ Q
100%
P
max
= F
max
/ Q
100%
)
Change flashing digit (cursor) with ↑ or ↓ key,
shift cursor 1 place to right with → key.
Press ↵ key to return to Fct. 1.06 PULS. P.
or
Please refer to Sect. 3.2 “factory settings”
→ VALUE P = set pulse value per unit time,
(appears only when ”PULSE/TIME” has been set under “SELECT P”), press → key.
• XXXX PulSe/Sec
• XXXX PulSe/min
• XXXX PulSe/hr
• XXXX PulSe/ user unit, factory-set: “hr”, see Sect. 5.12.
Select using ↑ or ↓ key.
Transfer to number setting with → key, 1st digit (cursor) flashes.
Set numerical value
• XXXX (setting range depends on pulse width)
Change flashing digit (cursor) with ↑ or ↓ key,
shift cursor 1 place to right with → key.
Press ↵ key to return to Fct. 1.06 PULS. P.
Refer to Sect. 2.4 for connection diagrams, and to Sect. 5.14 for characteristics.
