FIGURE 3-2. MASTER/SLAVE START-UP, COMPUTER DISPLAY (SHEET 1 OF 2)
4878 48780 38400 191 191 Baud OK
4878 4878
EEPROM Used: 287 bytes
78 48 45 4C:20 35 4B 2D:36 30 30 2D:32 30 30 20
30 33 2D 31:35 2D 32 30:31 30 00 00:00 00 00 00
00 00 00 00:00 00 00 00:00 00 00 41:31 30 34 35
30 33 00 00:00 00 00 00:00 00 00 00:00 00 00 00
00 FF 00 00:00 00 00 00:00 00 00 00:00 00 00 00
00 00 00 00:03 28 9A 01:00 50 34 03:00 3C 68 06
00 78 D0 0C:00 40 0D 03:00 05 03 18:31 0C 00 00
00 00 00 C0:27 09 00 80:8D 5B 00 20:12 0A 00 50
34 03 00 D0:1B 50 00 50:50 4D 33 32:30 30 00 00
00 00 00 00:00 00 00 00:00 00 00 00:00 00 00 00
00 00 00 00:00 00 00 00:00 00 00 00:00 00 00 00
02 20 12 0A:00 00 00 00:00 00 00 00:00 40 42 0F
00 01 00 00:00 C8 00 00:00 C8 00 00:00 B8 0B 00
00 94 2A 00:00 28 64 00:00 00 00 00:00 00 00 00
00 00 00 00:00 00 00 00:96 00 00 00:96 00 00 1A
04 00 00 E8:03 00 00 E8:03 00 00 2E:04 00 00 E8
03 00 00 D0:07 00 00 EC:FF 00 00 00:00 00 00 00
00 00 00 00:00 00 00 00:00 00 00 00:00 78 48
KEPCO, EL 5K-600-200 03-15-2010,A104503,MCB #234 1.219 $ 2010/03/26 12:58:08 $
KEPCO, EL 5K-600-200 03-15-2010,A104503,MCB #234 1.219 $ 2010/03/26 12:58:08 $
MEL (chassis) Serial Number: A104503
Calibration Settings
Calibrated Fullscale Ranges
100V 105000 mV
200V 210000 mV
400V 419900 mV
800V 839800 mV
Cutoffs
Current : 0.200
Voltage : 0.200
Power : 0.003
Max volt limit : 660.0
Max curr limit : 210.0
Max powr limit : 5.250
Setpoint scaling factor: 10.90
Setpoint Calibration Factors
Voltage : 1.050
Current : 1.000
Power : 1.000
Resistance : 1.070
Conductance : 1.000
Fan temperature limits (C)
Lower : 40
Upper : 100
External FB Gain : 2.000
Master Delay : -2000 uSec
EL Load boot up diagnostic
information verifying
communications baud rate
and memory check sums.
*IDN reply. See PAR. A.3
for details.
Load Calibration
Configuration Information
Note: These are factory
settings and are displayed
should diagnostic
information be required.
