SERIES EL 062011
3-1
SECTION 3 - OPERATION
3.1 GENERAL
This section contains general operating instructions for the Series EL Electronic Load. Refer to
Section 2 for a description of the controls, display and terminals. When loading sources of elec-
trical energy be sure to use appropriate precautions where high-currents and potentially high
voltages may be present.
WARNING
An electronic load can present an extremely low resistance to a source
of electrical energy. in some cases this may be the equivalent of
placing a short circuit at the source output. This may have disastrous
consequences if done unintentionally.
Be sure the load parameter settings are appropriate for the source
being tested.
3.2 FACTORY DEFAULT SETTINGS
The unit is shipped with the following settings preset at the factory:
• Current set point 0 A
• Voltage set point Load maximum voltage
• Power set point 0 kWatts
• Overvoltage limit 5% above rated maximum
• Undervoltage limit 0V (deactivated)
• Overcurrent limit 5% above rated maximum
• Overpower limit 5% above rated maximum
• Resistance set point 1,000 ohms
• Conductance set point 1 mS (0.001 siemens)
• System damping 5
• Mode damping 3
• Local control Fully enabled
• Load ON/OFF OFF
• DEB:ECHO OFF
