9. SAVING RESULTS
The
SAVE button can be used to store the displayed results related to the rotary switch
position:
SAFETY TEST and for AUX rotary switch position: pressing this key the instrument will
store the displayed result generating a corresponding record in the SAFETY TEST
MEMORY (see paragraph 11.1)
ANALYZER rotary switch position: pressing this key the instrument will store the
displayed result generating a "Smp" record in the ANALYZER MEMORY (see
paragraph 11.2)
Please note that Saving results is different from recording.
9.1.
SAVING SAFETY TEST RESULTS
After a SAFETY TEST (function LOW
Ω, MΩ, RCD, LOOP, Phase sequence, EARTH) or
during a real time measurement in AUX position the user can press the SAVE button to
store the displayed result.
05.06.01
Memory Location
REMINDER PARAMETER
SAVE IN LOC. 006
OK? (SAVE/ESC)
REMINDER PLACE:009
↑ ↓
The REMINDER
PLACE parameter
isn't related to
Measurement Order
Number and can help
the user to remind the
place where he
performed the
measurement.
The following keys are available:
F3, F4: to adjust the REMINDER PLACE.
SAVE:
to store the test result associating to the actual REMINDER PLACE
ESC:
to quit this mode without saving.
9.2.
SAVING DISPLAYED VALUES OF ANALYZER FUNCTION
During a Real Time measurement (in ANALYZER function) if the user press the SAVE
button, a "Smp" record will be generate in the "ANALYZER MEMORY". This file contains
the Voltage and Current values present at instrument's input when the user pressed the
SAVE key.
Downloading these values to a PC (using the management Software) the Power, Energy,
Harmonics, etc values can be calculated and displayed as well.
