SIRIUS89N
EN - 58
7.2. ENVIRONMENTAL PARAMETER AND LEAKAGE CURRENT: RECORDING
Before starting a recording we recommend You to check that real time values are correct.
To this purpose follow the measurement procedure described in paragraph 7.1.
In addition it's fundamental that Instrument settings correspond to the accessories is use.
For this we recommend you to check instrument's setting before execute an AUX
recording.
To this purpose please check the RECORDER CONFIG settings.
MENU: to enter in the MENU mode and change the instrument settings. It’s
not possible to enter the configuration MENU during a recording or an
energy measurement.
START/STOP: to record the selected parameters according to the instrument’s
settings (see chapter 10).
7.2.1. AUX Basic setting: RECORDER CONFIG
Place the rotary switch in the
AUX position, press the MENU key, using the F1/F2 keys
select the
RECORDER CONFIG item and press the ENTER Key.
MENU GENERAL
SAFETY TEST MEMORY
ANALYZER MEMORY
RESET
ANALYZER CONFIG
RECORDER CONFIG
CONTRAST
DATE&TIME
LANGUAGE
↓ ↑
Inside
RECORDER CONFIG mode it’s possible to execute the following operations:
• Setting of Start/Stop recording mode (AUTO or MANUAL) and the date/hour of
Start/Stop (in AUTO mode).
• Setting of Integration Period (see paragraph 16.13.1) selectable from 5 sec to 60 min
Press
ENTER to confirm each settings or ESC to escape from modifies and exit from
RECORDER CONFIG menu.
The various pages of the "
RECORDER CONFIG" can be schematised as follows:
CAUTION
It’s not possible to enter the MENU during a recording or a Real Time
Energy measurement.
