SIRIUS89N
EN - 33
RCD 05.06.01
- - -
ms
FRQ=50.0Hz Ut= ---V
VP-N=231V VP-PE= 0V
o CHANGE P-N
x1 30mA
50V
!
Phase and Neutral
Conductors are
exchanged.
FUNC
IdN RCD UL
This screen is displayed
when the phase
conductor has been
exchanged with the
neutral one.
The instrument does not
effect the test. Reverse
the shuko plug or
exchange the black
cable with the blue one.
Repeat the test
RCD 05.06.01
- - -
ms
FRQ=50.0Hz Ut= ---V
VP-N= 2V VP-PE= 230V
o CHANGE P-PE
x1 30mA
50V
!
Phase and Protection
Conductors are
exchanged.
FUNC
IdN RCD UL
This screen is displayed
when the phase
conductor has been
exchanged with the
Protection Conductors.
The instrument does not
effect the test. Reverse
the phase to earth
connection in the plug or
exchange the black
cable with the green one
RCD 05.06.01
- - -
ms
FRQ=50.0Hz Ut= ---V
VP-N=130V VP-PE= 227V
o CHANGE N-PE
x1 30mA
50V
!
Neutral and Protection
Conductors are
exchanged.
FUNC
IdN RCD UL
This screen is displayed
when in a 230V Phase
to Phase System the
blue conductor was
reversed with respect to
the green one.
The instrument does not
effect the test. Reverse
the blue and green
conductors.
