ON = the instrument is able to face situations of CO-GENERATION
of electrical equipment (that is, the equipment under test is
able to generate energy besides absorbing it). Accordingly, the
instrument will record the powers and energies both absorbed
and generated (see paragraph 16.12.1).
If this flag is
enabled the maximum number of parameters which can
be selected decrease to 38.
CO-GENERATION
OFF = the instrument will record ONLY the powers and energies
absorbed.
☺
P1 Active Power
☺
P1
Q1i Inductive Reactive Power
Q1c Capacitive Reactive Power
☺
Q1i Q1c
S1 Apparent Power
☺
S1
Pf1 Power factor
DPft1 cos
ϕ
☺
Pf1 dPf1
Ea1 Active energy
☺
Ea1
Eri1 Inductive reactive energy
Erc1 Capacitive reactive energy
☺
Eri1 Erc1
The value of the network frequency is automatically selected if the voltage is selected.
The symbols "i" and "c" stand for reactive powers (Q), power factors (Pf) and cos
ϕ (dpf) inductive and capacitive respectively.
Selecting a power factor (Pf) or a cos
ϕ (dPf) for the recording automatically their inductive value and their capacitive value will be
recorded separately.
For eventual messages displayed see Appendix 1 – MESSAGES DISPLAYED.
