1800
Ω
FRQ=50.0Hz Ut= 54V
VP-N=234V VP-PE= 34V
o UT NOT OK
R
A
30mA
50V
!
The instrument doesn't
detect an efficient
protection circuit.
FUNC
IdN RCD UL
Using the R
A
function,
if a contact voltage
U
t
higher than the
selected limit (U
L
) is
detected the instrument
emits
a long sound
signal at the end of the
test and displays the
screen alongside.
The test can be stored pressing the
SAVE key twice (according to paragraph 9.1).
6.3.3.2. RCD
tripping "faulty cases"
RCD 05.06.01
- - -
ms
FRQ=50.0Hz Ut= ---V
VP-N=231V VP-PE= 230V
o
RCD TRIPS
x1 30mA
50V
!
If the RCD trips during
the preliminary test
performed before the
test (independently from
the working mode) the
instrument displays the
screen alongside.
FUNC
IdN RCD UL
The RCD trips too early.
Check if the RCD Nominal
Current is correct.
Some leakage currents
may be present in the
installation. Disconnect all
the loads connected
downstream the RCD.
THE PREVIOUS RESULTS CAN'T BE SAVED.
RCD 05.06.01
RCD tripping time.
o
487
ms
FRQ=50.0Hz Ut= 1V
VP-N=231V VP-PE= 230V
o
TIME NOT OK
x1 30mA
50V
!
ATTENTION: the tripping
time is higher than the
standard limit.
FUNC
IdN RCD UL
In the tests MAN x1, x2,
x5 and AUTO (during x1
and x5 tests), if the RCD
trips to separate the
circuit within a time not
complying with the limits
reported in Table 3, the
instrument emits
a long
acoustic signal at the
end of the test and
displays the values
alongside.
The test can be stored pressing the
SAVE key twice (according to paragraph 9.1).
