6.3.2.5. Results of " R
A
" mode
4. Press the
START key once: the instrument carries out the test.
CAUTION
Never disconnect the test leads when the message
"MEASURING" is
displayed.
RCD 05.06.01 Global Earth Resistance
Value).
Value of contact voltage U
t
detected referred to the
rated value of the RCD
current set.
OK:Contact Voltage Not
Dangerous.
12
Ω
FRQ=50.0Hz Ut= 1V
VP-N=231V VP-PE=231V
Ut OK
RA 30mA 50V
!
The RCD must NOT
trip and the instrument
emits a
double sound
signal indicating the
positive outcome of
the test and displays the
screen alongside.
FUNC IdN RCD UL Contact Voltage Limit value
Working mode RCD nominal current RCD type
The test can be stored pressing the SAVE key twice (according to paragraph 9.1).
