Caution – HT instruments SIRIUS89N User Manual
Page 30
SIRIUS89N
EN - 28
6.3.2.1. Results of "x½" mode
4. Press the
START key once to execute a test with 0° Current waveform.
or
Press the
START key once to execute a test with 180° Current waveform.
CAUTION
Never disconnect the test leads when the message
"MEASURING" is
displayed.
RCD 05.06.01
The symbol
">" means that
the RCD did not trip.
Value of contact voltage
U
t
detected referred to the
rated value of the RCD
current set.
If the RCD
does NOT
trip the instrument emits
a
double sound signal
indicating the positive
outcome of the test and
displays the screen
alongside.
OK: RCD passed the test.
> 999
ms
FRQ=50.0Hz Ut= 1V
VP-N=231V VP-PE=231V
RCD OK
x1/2 30mA
50V
!
FUNC
IdN RCD UL
Contact Voltage Limit value
Working mode
RCD nominal current
RCD type
The test can be stored pressing the
SAVE key twice (according to paragraph 9.1).
6.3.2.2. Results of "x1, x2, x5" mode
4. Press the
START key once to execute a test with 0° Current waveform.
or
Press the
START key once to execute a test with 180° Current waveform.
CAUTION
Never disconnect the test leads when the message
"MEASURING" is
displayed.
RCD 05.06.01
Tripping time (expressed in
milliseconds).
Value of contact voltage
U
t
detected referred to the
rated value of the RCD
current set.
OK: RCD passed the test.
If the tripping time is
within the limits reported
in Table 3, the
instrument emits a
double sound signal
indicating the positive
outcome of the test and
displays the screen
alongside.
49
ms
FRQ=50.0Hz Ut= 2V
VP-N=231V VP-PE=231V
RCD OK
x1 30mA
50V
!
FUNC
IdN RCD UL
Contact Voltage Limit value
Working mode
RCD nominal current
RCD type
The test can be stored pressing the
SAVE key twice (according to paragraph 9.1).
START
STOP
START
STOP
