Interface overview, Rear panel overview, Nterface overview – GW Instek GDS-1000-U Series Programming Manual User Manual
Page 4
GDS-1000-U Programming Manual
4
I
NTERFACE OVERVIEW
This manual describes how to use the
GDS-1000-U’s remote command functionality and
lists the command details. The Overview chapter
describes how to configure the GDS-1000-U USB
remote control interface.
Rear Panel Overview
LINE VOLTAGE
AC 100 240V
FUSE RATING
RANGE
T1A 250V
FREQUENCY
50 60Hz
POWER MAX.
18W 40VA
USB port
CAL output
Power cord socket
Fuse socket
Security lock
slot
