GDS-1000-U Programming Manual
24
:CURSor:YPosition
Set
Query
Description Selects or returns the vertical (Y axis) cursor
position.
Same as: Cursor key →F5 (X-Y) → F2(Y1) or F3(Y2)
+
Vertical knob
Syntax < Long > < Short >
:cursor:yposition
:cursor:yposition? :curs:yp
:curs:yp?
Parameter Cursor 1 or 2 Cursor position
1 Cursor Y1 1 ~ 199 1 ~ 199 point
2 Cursor Y2
Note When in the query mode, the returned data format
is as follows.
CH1, CH2, Math (CH1±CH2): voltage (V)
Math (FFT): decibel (dB)
Example :cursor:ydisplay 1
:cursor:y1position 100 Puts the vertical
cursor Y1 on the 100
point position
:channel:math 3
:cursor:ydisplay 1
:cursor:y1position?
→ 2.500E+00 Returns the Y1 cursor
position as 2.5dB in
the Math FFT mode
CURSor:DELta
Query
Description Returns the distance between two horizontal (X
axis) or vertical (Y axis) cursors.
Same as: Cursor key →F5 (X-Y) → F4
Syntax < Long > < Short >
:cursor:delta? :curs:del?
