COMMAND DETAILS
23
Cursor Command
:CURSor:XPosition ................................................23
:CURSor:YPosition ................................................24
:CURSor:DELta ......................................................24
:CURSor:DISplay ...................................................25
:CURSor:SOURce .........................................................26
:CURSor:XPosition
Set
Query
Description Sets or returns the horizontal (X axis) cursor
position.
Same as: Cursor key → F5 (X-Y) →F2 (X1) or F3
(X2) + Variable knob
Syntax < Long > < Short >
:cursor:xposition
:cursor:xposition? :curs:xp
:curs:xp?
Parameter Cursor 1 or 2 Cursor position
1 Cursor X1 1 ~ 249 1 ~ 249 point
2 Cursor X2
Note When in the query mode, the returned data format
is as follows.
CH1, CH2, Math (CH1±CH2): time (s)
Math (FFT): frequency (Hz)
Example :cursor:xdisplay 1
:cursor:x1position 100 Puts the horizontal
cursor X1 on the 100
point position
:channel:math 3
:cursor:xdisplay 1
:cursor:x1position?
→ 2.500E+03 Returns the X1 cursor
position as 2500Hz in
the Math FFT mode
