GDS-1000-U Programming Manual
34
Example :measure:source 1
:measure:pwidth? Selects Channel 1, and
then measures the
positive pulse width.
:MEASure:RISe
Query
Description Returns the first pulse rising edge timing.
Same as: Measure key → F1~F5 → F3 (RiseTime)
Syntax < Long > < Short >
:measure:rise? :meas:ris?
Returns
Note Before using this command, select the
measurement channel. See the example below.
Example :measure:source 1
:measure:rise? Selects Channel 1, and
then measures the
rising edge timing.
:MEASure:ROVShoot
Query
Description Returns rise overshoot amplitude in percentage.
Same as: Measure key → F1~F5 → F3 (ROVShoot)
Syntax < Long > < Short >
:measure:rovshoot? :meas:rovs?
Returns with % sign
Note Before using this command, select the
measurement channel. See the example below.
Example :measure:source 1
:measure:rovshoot? Selects Channel 1, and
then measures the rise
overshoot.
