COMMAND DETAILS
21
±5.0 –5.0V ~ +5.0V
(100mV/div~500mV/div)
±50.0 –50.0V ~ +50.0V
(1V/div ~ 5V/div)
Example :channel1:scale 1.00e–2
:channel1:offset 2.00e–2 Sets the Channel 1
scale to 10mV/div
Sets the Channel 1
offset to 20mV
:CHANnel:PROBe
Set
Query
Description Sets or returns the probe attenuation factor.
Same as: Channel key → F4
Syntax < Long > < Short >
:channel:probe
:channel:probe? :chan:prob
:chan:prob?
Parameter Channel Probe attenuation factor
1/2 CH1/2 0 1x
1 10x
2 100x
Example :channel1:probe 1 Sets the Channel 1
probe attenuation
factor to 10x
:CHANnel:SCALe
Set
Query
Description Sets or returns the vertical scale. The scale depends
on the probe attenuation factor.
Same as: Volts/Div knob
Syntax < Long > < Short >
:channel:scale
:channel:scale? :chan:scal
:chan:scal?
