COMMAND DETAILS
25
Parameter Horizontal or vertical cursor
x Horizontal cursor (X axis)
y Vertical cursor (Y axis)
Note The returned data format is as follows.
CH1, CH2, Math (CH1±CH2): time (s) for
horizontal cursor, voltage (V) for vertical cursor
Math (FFT): frequency (Hz) for horizontal cursor,
decibel (dB) for vertical cursor
Example :channel:math 3
:cursor:xdisplay 1
:cursor:xdelta?
→ 2.500E+03 Returns the frequency
(2500Hz) between the
two horizontal cursors
in the Math FFT mode
:channel:math 3
:cursor:ydisplay 1
:cursor:ydelta?
→ 2.500E+00 Returns the decibel
(2.5dB) between the
two vertical cursors in
the Math FFT mode
:CURSor:DISplay
Set
Description Turns the horizontal or vertical cursors on/off.
Same as: Cursor key
Syntax < Long > < Short >
:cursor:ydisplay :curs:ydis
Parameter X or Y cursor Cursor on/off
x X (horizontal) 0 off
y Y (vertical) 1 on
Example :cursor:ydisplay 1 Turn Y cursor on
