COMMAND DETAILS
35
:MEASure:RPReshoot
Query
Description Returns rise overshoot amplitude in percentage.
Same as: Measure key → F1~F5 → F3 (RPReshoot)
Syntax < Long > < Short >
:measure:rpreshoot? :meas:rpr?
Returns with % sign
Note Before using this command, select the
measurement channel. See the example below.
Example :measure:source 1
:measure:rpreshoot? Selects Channel 1, and
then measures the rise
preshoot.
:MEASure:SOURce
Set
Query
Description Selects the measurement channel.
Same as: Measure key → F1~F5 → F1, F2
Syntax < Long > < Short >
:measure:source
:measure:source? :meas:sour
:meas:sour?
Parameter
1 ~ 2 Channel1 ~ 2
Example :measure:source 1
:measure:rprshoot? Selects Channel 1, and
then measures the rise
preshoot.
:MEASure:VAMPlitude
Query
Description Returns the voltage difference between positive
and negative peak.
Same as: Measure key → F1~F5 → F3 (Vamp)
