Appendix A
86 Avaya C460 SMON User Guide
Using the Define TopN Filter Dialog Box
You can also filter using the TopN option. TopN filtering differs from item
filtering in that SMON chooses the items with the heaviest traffic. The
TopN filter produces a report for the 1-15 (N) most active items on the
network.
SMON chooses the TopN items by a rate base which you select from the
Define TopN Filter dialog box. SMON measures the rate base for all the
items to find the TopN items and then displays these items and their
statistics.
* Note: If you previously defined a filter, TopN will select the TopN
items from the specified subset.
To select the criterion for TopN Configuration:
1. Click .
Or
Select Actions > Define Top N Filter . The Define TopN Filter dialog
box opens.
Figure A-7. Define TopN Filter Dialog Box
2. Select the number of items and the criterion for the TopN filter.
* Note: Filtering changes are only applied after clicking Apply .
