Avaya C460 SMON User Guide

Using VLAN Statistics

VLAN
Filtering

You can filter the VLANs displayed in the VLAN Statistics window by
VLAN. Only selected VLANs are displayed in the VLAN Statistics window.
This makes it easier to concentrate on specific VLANs in the network.

To open the Define VLAN Filter dialog box:

Click .

Select

View >

Define VLAN Filter

. The Define VLAN Filter dialog box

opens.

Figure 6-3. Define VLAN Filter Dialog Box

To add VLANs to the

Selected VLANs

list:

Select VLANs from the

Known VLANs

list and click

Double-click VLANs in the

Known VLANs

list. The selected VLANs

appear in the

Selected VLANs

list.

To select all VLANs, click

. All VLANs are added to the

Selected VLANs

list.
