Avaya C460 SMON User Guide

Using Alarms and Events

Select Ports

The Select Ports screen of the Alarm Wizard allows you to select ports and
LAGs to be monitored by the alarm.

Figure 7-4. Alarm Wizard - Select Ports

The ports and LAGs on the device are listed in the

Device Ports

list.

To select ports and LAGs to monitor, double-click a port or LAG in the

Device Ports

list. The selected port or LAG appears in the

Selected Ports

list.

To remove ports or LAGs from the

Selected Ports

list, double-click a port or

LAG in the

Selected Ports

list. The selected port or LAG is removed from the

Selected Ports

list and appears in the

Device Ports

list.

When defining an alarm for more than one port, a separate alarm is
created for each port.

* Note: A maximum of 150 alarms can be defined on a device.

When you finish selecting ports and LAGs to monitor, click

Next

. The

Alarm Wizard continues with the

screen.
