Chapter 6
40
Avaya C460 SMON User Guide
Viewing VLAN Bandwidth Statistics
The following graphic displays the VLAN Bandwidth Statistics window.
Figure 6-2. VLAN Statistics Window - Bandwidth
The following table provides a list of the variables available in the
VLAN Statistics - Bandwidth window.
Selecting VLANs to Display
By default, information from all VLANs is displayed in the VLAN Statistics
window. You can limit information being displayed to specific VLANs
using VLAN and TopN filters. In addition, you can sort the display. For
information on sorting the display, refer to
Table 6-2. VLAN Statistics Variables - Bandwidth
Variable
Description
In BW (Kbps)
The rate at which traffic is entering the VLAN.
