Chapter 9
70
Avaya C460 SMON User Guide
•
•
Adding
Protocols
The
User Protocols
list can only contain seven protocols. Before adding a
protocol when there are already seven, you must remove a protocol from
the list. For more information on deleting protocols, refer to
To add listed protocols to the
User Protocols
list:
Double-click the protocol to monitor in the
Protocol List
.
Or
Select one or more protocols in the
Protocol List
, and click
Add
. The
selected protocol is added to the
User Protocols
list and is highlighted
in cyan.
Adding a
User
Defined
Protocol
This feature enables you to add a new protocol that does not exist in the
Protocol List
or
Active Protocols List
.
To add a new protocol:
1. Select the
User Defined
tab.
Figure 9-3. User Defined Protocol Dialog Box
2. Enter the protocol description in the
Description
field.
3. Enter the port number in the
Port
field, an integer from 1 to 8191.
4. Select the port type, UDP or TCP, from the
Type
pull-down list box.
5. Click
Add
. The new protocol is added to the
User Protocols
list
highlighted in cyan.
6. Click
Apply
. The new protocol information is sent to the device.
