Avaya C460 SMON User Guide

Using Port Statistics

To remove VLANs from the

Selected VLANs

list:

Select VLANs in the

Selected VLANs

list

and click

Double-click VLANs in the

Selected VLANs

list. The selected VLANs

are removed from the

Selected VLANs

list.

To remove all items from the

Selected VLANs

list, click

. All VLANs are

removed from the

Selected VLANs

list.

To refresh the

Known VLANs

list, click

Refresh

To apply the VLAN filter, click

Apply

. The Port Statistics information is

filtered.

To define the VLAN filter without applying it, click

To toggle the VLAN filter:

Click .

Select

View > Activate VLAN Filter

TopN Port
Filtering

TopN filtering enables SMON to display only the items with the heaviest
traffic. The TopN filter produces a report for the 1-15 (N) most active
items on the network.

SMON selects the TopN items by a rate base which you select from the
pull-down listbox in the Port Statistics window. SMON measures the rate
base for all the items to find the TopN items and then displays these items
and their statistics.

For information on defining the number of items to display using TopN
filtering, refer to

“Port/VLAN Tab” on page 79

To activate the TopN filter, click

at the bottom of the Port Statistics

window. To deactivate the TopN filter, click

at the bottom of the Port

Statistics window.

To select a rate base, select a TopN criteria from the

TopN

pull-down

listbox at the bottom of the Port Statistics window.
