Chapter 4
26 Avaya C460 SMON User Guide
Selecting Ports to Display
By default, information from all ports and LAGs is displayed in the Port
Statistics window. You can limit information being displayed to specific
ports using Port, VLAN, and TopN filters. In addition, you can sort the
display. For information on sorting the display, refer to
“Sorting the Port
Display” on page 30 .
This section provides information about the following topics:
• Port Filtering
• VLAN Filtering
• TopN Port Filtering
Port
Filtering
You can filter the ports and LAGs displayed in the Port Statistics window.
Only selected ports are displayed in the Port Statistics window. This makes
it easier to concentrate on specific ports and LAGs in the network.
To open the Define Port Filter dialog box:
Click .
Or
Select View > Define Port Filter . The Define Port Filter dialog box
opens.
Figure 4-5. Define Port Filter Dialog Box
