Avaya C460 SMON User Guide 77
Using Avaya C460 SMON Dialog Boxes
Switch Tab
This tab enables you to change the display options for Switch Statistics for
the Avaya C460 Device.
To access the Switch tab, click the Switch tab at the top of the Options
dialog box. The Switch tab opens.
Figure A-2. Options Dialog Box - Switch Tab
* Note: Changes made in the Switch Statistics Options dialog box
apply to Switch Statistics and Extended Port Statistics.
The Switch Options dialog box enables you to change the following
options:
• Samples Per Screen
• Samples To Store
• Logarithmic Display
• Level Indicators
Samples Per
Screen
The Samples Per Screen option enables you to configure the number of
samples visible in the Traffic Graph. To change the number of samples
visible on the screen, enter a number in the
Samples Per Screen field.
* Note: The number of samples per screen must be between 3 and
500.
