Using the VLAN Statistics Window
The VLAN Statistics window is organized as follows:
•
The title of the VLAN Statistics window displays the IP address of
the device.
•
The X axis relates to packets over time or total packets, depending
on the display mode (refer to
).
•
The Y axis relates to the VLAN name. Only VLANs with member
ports or LAGs appear in the window. If no VLANs have been
defined, the “Default” or “Generic” VLAN includes all traffic.
For more information about modifying the display, and the available
toolbar, status bar and mouse movement options, refer to
This section discusses the following topics:
•
Viewing VLAN Packet Statistics
•
Viewing VLAN Bandwidth Statistics
•
•
