EVOLUTION 3001 FRONT PANEL
Navigator
Buttons
Optional
Natural
Stages
Stage switches
(ON, OFF,
AUTO)
'Stage On'
Indicators
White spaces
are for stickers
to identify stage
operations
Editor Buttons
Main Display
(Larger Scrolling Area)
Optional
Ventilation
Stages
Stage switches
(ON, OFF, AUTO)
'Stage On' Indicators
White spaces are for
stickers to identify
stage operations
EVOLUTION 3000 EXPANSION STAGES FRONT PANEL
