Part No. 4801-5307 Rev 2-10 Evolution 3000 and 3001 51 of 70
PowerTrak
AUX
SWITCH
CONTROLLER AC IN
HOT
NE
UT
.
LOW
E
R
GND
.
HOT OUT
CL
OSE IN
O
PEN IN
COM
U
PPE
R
9.10 Connecting the PowerTrak to the Evolution 3000 & 3001
NOTE: If curtain is setup to pull curtain up to open, then reverse wires connected to "OPEN" and "CLOSE"
terminals.
NOTE: Only 1 Power Trak can be connected to each Power Trak outlet. If Additional Power Traks are needed,
Then use of relay boxes is necessary to separate the load.
NOTE: All PowerTrak units will connect the same.
Inset A
Unit #2 Vents
Unit #2 Vents
COM Close Open
Inset B
Inset B
J1
J2
Hired - Hand
B. Crider
D 1 D 2 D 3 D 4
Copyright (c) 2000
PCB 167 Rev ‘0’
CO
M
Op
en
Cl
os
e
Un
it #
1 (V
en
ts )
CO
M
Op
en
Cl
os
e
U nit
#
2 (
Tun
ne
l)
+12V Open
U1
Relay Control
Close
U1
Open
U2
Close
U2
HIRED-HAND RLY 1 RLY 2 RLY 3 RLY 4
Inset A
PCB – 167 Power Ventilation
WARNING!
Keep High Voltage (Or AC)
Separate From Low Voltage
Wires!
Evolution 3000 / 3001
