Warning – Hired-Hand Evolution Series 3000/3001 User Manual
Page 47
Part No. 4801-5307 Rev 2-10
Evolution 3000 and 3001
47 of 70
9.4
Connecting Static Pressure Sensor to Evolution
3000 & 3001
9.5
Connecting Humidity Sensor to Evolution
3000 & 3001
Inset A
Inset A
R
e
d
W
h
t
B
lk
C
O
M
O
U
T
EX
C
Pressure Sensor
WARNING!
LOW VOLTAGE!
Keep Separate From
High Voltage Wires!
Inset A
Inset A
Humidity Sensor
WARNING!
LOW VOLTAGE!
Keep Separate From
High Voltage Wires!
PCB 169
PCB 169
Black
Brown
Blue
Cooler House
