Part No. 4801-5307 Rev 2-10 Evolution 3000 and 3001 41 of 70
**Password Setup**
Enter a new password for this
controller and press ENTER:
New Password: 0000
**DIAGNOSTICS**
"
For Qualified Technician Use Only:
(1)Power Ventilation Auxilary SWX:
(2)Ignore Inlet #1 Auxiliary SWX = Yes
(3)Ignore Inlet #2 Auxiliary Swx = Yes
(4)Natural Ventilation Auxiliary SWX:
(5)Ignore Unit #1 Auxiliary SWX = Yes
(6)Ignore Unit #2 Auxiliary Swx = Yes
(7)Feed Level Sensor:
(8)Maximum Range = 26.00 ft
(9)Dead Zone = 1.50 ft
(10)GPAD12 = 115
GPAD13 = 105
GPAD14 = 98 GPAD15 = 90
(11)Soft Resets = 0
(12)Voltage Resets = 0
(13)Hard Resets = 0
(2) Program Name – The program name can be changed to include a special title, letters, numbers, and
characters up to 8 digits in length.
(3) Copy to Program – Enter the COPY TO program number (0, 1, or 2).
(4) Enter to Proceed – When “Enter to Proceed” is selected and the ENTER button is pressed, the Copy to
Program number programming contents is replaced with the programming contents of the Seasonal
Program number.
NOTE: This action is not reversible.
(5) Change Password – Select “Change Password” for
changing the existing password for the Controller. The
four digits will allow a numeric password from 0001 to
9999. Changing the Password to 0000 disables the
locks until the password is changed to a number
between 0001 and 9999.
NOTE: Record the password in a convenient retrievable location.
7.14 Diagnostics
The Diagnostics screen is for qualified
technician use only and can only be
changed by using the service code.
Contact the local dealer for assistance.
(1) Power Ventilation Auxiliary SWX -
Setting these options to Yes will
ignore the indication from the curtain
switch. This feature will totally
ignore the auxiliary switches on the
PT machines when answered yes.
Note: This must be answered 'No' and the
open auxiliary switch of the vent
machine must be connected in
order to use the feature of running
the tunnel curtain with the vents
during Power ventilation when the
pressure is to high and the vents are
completely open.
(2) Ignore Inlet #1 Auxiliary Switch - Yes or No
(3) Ignore Inlet #2 Auxiliary Switch - Yes or No
(4) Natural Ventilation Auxiliary SWX - Setting these options to Yes will ignore the indication from the
curtain switch. This feature will totally ignore the auxiliary switches on the PT machines when
answered "Yes".
Note: The auxiliary switches must be connected and this answered to no in order for the control to enter
into natural ventilation.
(5) Ignore Unit #1 Auxiliary Switch - Yes or No
(6) Ignore Unit #2 Auxiliary Switch - Yes or No
(7) Feed Level Sensor – Settings for setting the maximum range and calibration of the feed level sensor.
(8) Maximum Range - Total sensing range of the sensor.
(9) Dead Zone - Distance from the top of the feed bin to the bottom of the sensor.
