Warning – Hired-Hand Evolution Series 3000/3001 User Manual
Page 56
Part No. 4801-5307 Rev 2-10
Evolution 3000 and 3001
56 of 70
NOTE: Set slide switch
to the voltage of the
power supply connected.
Controllers shipped
from HHI set to 240V.
Evolution Back-up
Cabinet
Evolution 3000 16 Stage
Ex
p
ansion Module
Evolution 3000
Cabinet
Eart
h Ground
Hot
Neutral
Breaker
Panel
Eart
h Ground
Hot
Neutral
AC
Junc
tion
Bo
x
Earth GND
Hot
Neutral
Eart
h Ground
Hot
Neutral
NOTE:
R
un power
C
abl
es i
n
cl
udi
ng eart
h
Ground from each
C
abi
net
t
o
a common
AC
j
unct
ion box.
Al
so connect
ground
To backplate.
230 V
115 V
NOTE: Run power cables including
earth ground from each cabinet to a
common AC junction box. Do NOT run
AC power and ground between cabinets.
AC
Ju
ncti
on
Box
Inset A
(AC Input on
PCB 169)
Earth GND
Hot
Neutral
WARNING!
Keep High Voltage (Or AC)
Separate From Low Voltage Wires!
9.15 Power Supply Connection
