Hired-Hand Evolution Series 3000/3001 - Manual (Page 62)

Part No. 4801-5307 Rev 2-10 Evolution 3000 and 3001 62 of 70
Circuit Boards
6407-1511 PCB161 EV fail safe rly w QA
6407-1513 PCB161 EV relay w QA
6407-1516 PCB167 EV curtain rly w QA
6407-1518 PCB168 EV 16 Stg SWX w QA
6407-1520 PCB169 EV Master I/O w QA
6407-1522 PCB170 EV 3000 Interface w QA
6407-1523 PCB170 EV 3001 Interface w QA
6407-1592 PCB170 EV 3000 Spanish Interface w QA
6407-1593 PCB170 EV 3001 Spanish Interface w QA
6407-1526 PCB171 EV backup PS w QA
6407-1528 PCB171 EV 16 Stg PS w QA
6407-1536 PCB172 EV-Variable w/QA
6407-6011 EV-3000 Display Assy. (LCD Display only)
6407-6026 EV Back-up Door Assy.
6407-6050 EV-3001 Display Assy. (LCD Display only)
6407-1538 PCB174 Dimmer M/A w/QA
Chips
3701-6061 FLASH EV3000 (For PCB170)
3701-6065 FLASH EV3001 (For PCB170)
3701-6076 FLASH Spanish EV3000 (For PCB170)
3701-6077 FLASH Spanish EV3001 (For PCB170)
3701-6062 PIC EV3000 (For PCB170)
3540-0148 EEPROM 25C640 (For U10 and U11 of PCB170)
3701-6063 PIC EV300X I/O (For PCB169 rev A or 0, Use software Rev0.02 or earlier)
3701-6078 PIC EV300X B I/O
(For PCB169 rev B or later, use software Rev0.03 or later)
3701-6064 PIC EV-Backup (For PCB163)
Fuses
3010-2991 FUSE 3 AMP 5mmX20mm (For PCB169 and 171)
3010-2540 FUSE 20 A 1/4X1-1/4 (For PCB172-Variable Modules)
Terminal Blocks
3006-5076 CONN TBLK 2 pos EBY (Black)
3006-5077 CONN TBLK 3 pos EBY (Black)
3006-5078 CONN TBLK 4 pos EBY (Black)
3006-5079 CONN TBLK 5 pos EBY (Black)
3006-5082 CONN TBLK 3 pos Magnum (Green)
