Hired-Hand Evolution Series 3000/3001 - Manual (Page 25)

Part No. 4801-5307 Rev 2-10 Evolution 3000 and 3001 25 of 70
** (1)EV300x v0.32 **
(2)HHNet Address = 1
(3)Optimum Mode = Off
(3)Growout Start Date = 15 Jun 2003
(4)Preheat Mode = Off
(5)Date = 21 Feb 2007
(6)Day = Wed
(7)Time = 05:20p
(8)Units of Measure = English
(9)Pressure Units = Inches of wc
(10)Water Meter-Pulses Per Unit - 100
**SENSOR SETUP**
(1)Room Temperature Sensors = --6-4-2-
(2)ALARM on Outside Sensor Error = Off
(3)SENSOR (4)ENABLED (5)VALUE (6)ADJUSTED
1 ON 77.0 + 3.0°
2 ON 77.0° + 1.0°
3 ON 77.0° +00.0°
4 OFF 77.0° +00.0°
5 OFF 77.0° +00.0°
6 OFF 77.0° +00.0°
7 OFF 77.0° +00.0°
8 OFF 77.0° +00.0°
OUT ---- 77.0° +00.0°
7. Setting Programming Functions
This section discusses the programming screens for the Evolution 3000 and 3001.
7.1 General Settings
The General Settings contains parameters that usually only need to be set once when the system is
installed. To change any of these parameters, use the EDITOR arrows to navigate through the list and the
plus (+) and minus (-) buttons to increase or decrease the values.
(1) Software Version – The software version currently in use.
(2) HHNET Address - HH.Net permits up to
32 controllers to be addressed on a single
communications port of a personal
computer (PC). In order for the computer
to recognize the communications from the
controllers, each controller must have a
unique network address. For example: If
you have an Evolution 3000 or 3001, a
Stage Master, and two Power Vents you
would need to set the Evolution to address
1, the Stage Master to address 2, the first
Power Vent to address 3, and the second
Power Vent to address 4. Valid settings
are: 1 - 32. (You do not have to address the
controllers in any particular order.)
(3) Optimum Mode – On or Off. Refer to
Section 7.6.2 for a detailed description of
the Optimum Mode features and options.
(4) Growout Start Date - Set the date desired
to start the grow-out. Evolution will use this
date to control the feed, light clock and
ramping functions. NOTE: This must be
set to the first day of grow-out. Your
historical data will start at this date and go
for 99 days or until the next grow-out date
has been set and then that date has been
passed.
(5) Preheat Mode – On or Off
(6) Date – The current date as Day/Month/Year.
(7) Day – The current day of the week.
(8) Time – The current time.
(9) Units of Measure - The units of measure can be
selected as English or Metric.
(10) Pressure Units - Pressure units can be selected
as inches of water column or Pascals.
(11) Water Meter-Pulses Per Unit – HH standard
water meter is one pulse per gallon. Select a
value from 1 to 100.
7.2 Temperature Sensors
The Sensor Set-Up screen is used to set the temperature sensors that will be used to determine the internal
temperature of the building.
(1) Room Temperature Sensors - Select any
or all of the internal sensors. Your alarm
high and low limits will use these sensors
that are displayed here.
For example: If you wanted to display
sensors 1,2,3,4,5 for your room temperature
it would look like this: "---54321" If you
turn all the sensors off (by setting it to -) the
control would use the outside temperature
and it would look like this: "Outside-".
(2) Alarm on Outside Sensor Error – On or Off.
(3) Sensor – Identifies up to eight inside and one
outside sensor.
(4) Enabled – Yes or No.
(5) Value – Current temperature reading.
(6) Adjusted – This will indicate if the sensor temperature has been calibrated and the amount of re-
calibration.
