IM DA100-01E 4-8
Transportation and Storage Conditions
These refer to the environmental conditions existing during transportation and storage from the
time of shipment from the factory until commencement of use, and also during transportation and
storage in case of temporary non-use. If the environmental conditions are maintained within the
specified range, the unit will not incur permanent damage, and can be returned to a normal
working condition (re-adjustment may be required in some cases.)
Ambient temperature
–25 to 60 °C
Humidity
5 to 95% RH
Vibration
10 to 60 Hz 4.9m/s 2 max.
Shock
392 m/s 2 max (in packed condition)
Other Specifications
Clock
With calendar function; be sure to set when the power is ON.
Clock accuracy
±100ppm
System alarm
Contact output (when DI/DO is connected)
Back-up of setting parameters
Lithium battery back-up (approx. 10 years), excluding clock function (time and date are reset to
96/1/1 0:00 each time the power is turned ON.)
Insulation resistance
At least 20M
Ω between each terminal and ground (at 500 VDC)
Withstand voltage
· Between AC power supply terminal and case of DA100 main unit:
1500 VAC (50/60Hz) for one minute
· Between AC power supply terminal and the case of the subunit:
1500 VAC (50/60Hz) for one minute
· Between DC power supply terminal and the case of DA100 main unit:
1000 VAC (50/60Hz) for one minute
· Between DC power supply terminal and the case of the subunit:
1000 VAC (50/60Hz) for one minute
· Between input teminal and case of DA100 main unit:
1500 VAC (50/60Hz) for one minute
· Between output teminal and case of DA100 main unit:
2300 VAC (50/60Hz) for one minute
EMC Conformity Standards
· Emission EN55011: Class A
· Immunity EN50082-2
IEC1000-4-2 Electrostatic Discharge Performance Criteria A*
8kV(Air), 4kV(Contact)
IEC1000-4-3 Radiated fields Performance Criteria A*
80 to 1000MHz, 10V/m
IEC1000-4-4 Fast Transients Performance Criteria B
Power line 2kV, The others 1kV
IEC1000-4-6 Conducted Disturbance Performance Criteria A*
0.15 to 80MHz, 10V
* Effect on accuracy
Universal input module and DCV/TC/DI input module
±10% of range (except for 50V range)
±20% of range (50V range)
When the extension module is used
±20% of range (except for 50V range)
±40% of range (50V range)
Strain input module
±10% of range (except for 2000 µε range)
±50% of range (2000 µε range)
Other input module
±10% of range
4.1 DA100/ DS400/ DS600
