Retransmission module – Yokogawa DA100 User Manual
Page 19
IM DA100-01E
1-9
1
System Configuration
RS-422-A/RS-485 module (DT300-31)
ON/OFF switch of built-in terminating resistor
LED
Switches to set
communication parameters
RS-422-A/RS-485 terminal
Ethernet module (DT300-41)
Switch to set mode
Status indicator
10BASE-T port
Retransmission Module
1-5 V Retransmission module (DT500-11)
Screw terminal
Cover
4-20 mA Retransmission module (DT500-21)
Cover
Screw terminal
1.3 Name and Function of Each Part
