2.4 Connecting the Interface Cables
Minimum response time (No.1 to 3 of Switch3)
Minimum response time
No.1
No.2
No.3
0ms
OFF
OFF
OFF
←Default
Setting
10ms
OFF
OFF
ON
20ms
OFF
ON
OFF
50ms
OFF
ON
ON
100ms
ON
OFF
OFF
Address (No.4 of Switch3 and No.1 to 4 of Switch4)
Address
No.4(Switch3) No.1(Switch4) No.2(Switch4) No.3(Switch4) No.4(Switch4)
1
OFF
OFF
OFF
OFF
ON
←Default Setting
2
OFF
OFF
OFF
ON
OFF
3
OFF
OFF
OFF
ON
ON
4
OFF
OFF
ON
OFF
OFF
5
OFF
OFF
ON
OFF
ON
6
OFF
OFF
ON
ON
OFF
7
OFF
OFF
ON
ON
ON
8
OFF
ON
OFF
OFF
OFF
9
OFF
ON
OFF
OFF
ON
10
OFF
ON
OFF
ON
OFF
11
OFF
ON
OFF
ON
ON
12
OFF
ON
ON
OFF
OFF
13
OFF
ON
ON
OFF
ON
14
OFF
ON
ON
ON
OFF
15
OFF
ON
ON
ON
ON
16
ON
OFF
OFF
OFF
OFF
17
ON
OFF
OFF
OFF
ON
18
ON
OFF
OFF
ON
OFF
19
ON
OFF
OFF
ON
ON
20
ON
OFF
ON
OFF
OFF
21
ON
OFF
ON
OFF
ON
22
ON
OFF
ON
ON
OFF
23
ON
OFF
ON
ON
ON
24
ON
ON
OFF
OFF
OFF
25
ON
ON
OFF
OFF
ON
26
ON
ON
OFF
ON
OFF
27
ON
ON
OFF
ON
ON
28
ON
ON
ON
OFF
OFF
29
ON
ON
ON
OFF
ON
30
ON
ON
ON
ON
OFF
31
ON
ON
ON
ON
ON
Connecting the RS-422-A/RS-285
For details on connectin the RS-422-A/RS-485 connector of the RS-422-A/RS-485
communication interface module to a personal computer, see IM DA100-11E, “DA100
Communication Interface User’s Manual.”
CAUTION
When (dis) connecting the RS-422-A/RS-485 cable, turn OFF the power of
both the personal computer and the instrument. If the power is not turned
OFF, malfunctions may occur and the internal circuitry may be damaged.
