IM DA100-01E

4-7

4

Specifications

Ambient temperature

· Stand-alone type main unit/expandable type main unit

when floor-mounted

: 0 to 50

°C

when panel-mounted

: 0 to 50

°C

· DS400/DS600 Subunit

when floor-mounted

: 0 to 50

°C

when panel-mounted

: –10 to 60

°C

Ambient humidity

20 to 80%RH for –10 to 40

°C, 10 to 50%RH for 40 to 50°C, 5 to 30%RH for 50 to 60°C (no condensation)

Vibration

10 to 60Hz, 0.2m/s

2

Shock

not allowed

Magnetic field

400 A/m max (50/60 Hz)

Position

Mount the unit left-right horizontally or vertically, as a general rule.

Installation location

Room

Installation height

Altitude up to 2,000 m

Installation category based on IEC 1010-1

II*

1

Pollution degree based on IEC 1010-1

2*

2

Warm-up time

At least 30 minutes after power switch-on.
*

1

Installation category is the specification of the inpuls withstanding voltage which is also called
as overvoltage category.

*

2

Polution degree is the level of foreign body adhesion such as the solid, liquid, and gas which
decrease the withstanding voltage, 2 means general indoor atmosphere.

Standard Performance

Reference operation conditions

temperature: 23

±2°C; humidity: 55 ±10% RH; supply voltage 90 to 250 VAC (AC power supply)

/10 to 32 VDC (DC power supply); supply frequency: 50/60

±1% (AC power supply); warm-up

time: at least 30 minutes; when operating, the system must not adversely affect the operation of
other equipment.

Effect of Operating Conditions

Ambient temperature: variation for a temperature change of 10

°C: within ±(0.1% of rdg + 1

digit);

±(0.2% of span + 1 digit) for Cu10Ω

Voltage variation: within

±1 digit over the range of 90 to 250 VAC (frequency 50/60 Hz, for AC

power supply) /10 to 32 VDC (for DC power supply)
External magnetic field: variation with respect to AC (50/60 Hz) and DC magnetic fields of 400
A/m: within

± (0.1% of rdg + 10 digits)

Except for the power monitor module: within

±15% of range

Signal source resistance: variation with respect to signal source resistance 1k

Ω change

(1)voltage

2 V range or below: within

±10µV

6 V range or above: within

±0.1% of rdg

(2)thermocouple

within

±10µV; however it must be within ±100µV when burnout is specified.

(3)RTD

variation with respect to change of 10

Ω per wire (when all wires have the same resistance

value)
indication: within

±(0.1% of rdg + 1 digit)

variation in indication with respect to a difference of 40 m

Ω in the resistance between

conductors (max, difference between 3 wires): approx. 0.1

°C (in case of Pt100)

Mounting position

Variation when the unit is mounted horizontally on a panel: within

±(0.1% of rdg + 1 digit)

Vibration

Variation when sinusoidal vibration of acceleration 0.2 m/s

2

is applied for two hours in each of

the 3 axial directions over a frequency range of 10 to 60 Hz: within

±(0.1% of rdg + 1 digit)

4.1 DA100/ DS400/ DS600
