Specifications
4.1 DA100/ DS400/ DS600
Style Number DA100: S8
DS400: S8
DS600: S8
Available Modules for the DA100 Stand-alone Type
Input modules : universal (DC voltage, TC, RTD, contact), DCV/TC/DI, mA,
Power monitor, Strain, Pulse, Digital
Alarm output modules : 4-ch output (transfer contact) or 10-ch output (make contact);
the number of channels can be increased by adding modules.
Communication interface modules : Selectable from GP-IB, RS-232C, RS-422-A/RS-485, and
Ethernet
DI/DO modules : 2-ch alarm output (transfer contact), 1-ch fail output and 12-
ch remote control input for only with /M1 opution
Extender module
· Number of modules which can be connected : 6 (of which at least one must be a communication
interface module)
DI/DO module: not more than one
Input module: max. four
Input module + alarm output module + DI/DO module + communication interface module:
max. six
Connecting the DA100 Expandable Type Subunits
Types of subunits
Subunit DS400: four modules
Subunit DS600: six modules
Number of subunits which can be connected
Up to six units can be connected (either DS400 or DS600)
Connection method
Using dedicated cables
Available Modules for the DA100 Expandable Type
Main unit
Alarm output modules : 4-ch output (transfer contact) or 10-ch output (make
contact); the number of channels can be increased by adding
modules.
Communication interface modules : Selectable from GP-IB, RS-232C, RS-422-A/RS-485, and
Ethernet
DI/DO modules : 2-ch alarm output (transfer contact), 1-ch fail output and 12-
ch remote control input for only with /M1 opution
Extender module
· Number of modules which can be connected: 4 (of which at least one should be a communication
interface module)
Alarm output module + DI/DO module: not more than three
Input module: cannot be connected.
Subunit (DS400/DS600)
Input modules : universal (DC voltage, TC, RTD, contact), DCV/TC/DI, mA, Power
monitor, Strain, Pulse, Digital
Alarm output modules : 4-ch output (transfer contact) or 10-ch output (make contact); the
number of channels can be increased by adding modules.
DI/DO modules : Alarm 2-ch output (transfer contact) and fail output module
Extender module
· Number of modules which can be connected to one DS400: 4
Input module + alarm output module + DI/DO module: max. four
· Number of modules which can be connected to one DS600: 6
Input module + alarm output module + DI/DO module: max. six
