Specifications
4.13 Dimensional Drawings
DA100 Stand-alone type / Subunit DS600
Unit:mm
156
168
20
100 422
145
22 162 55
176
115
369
20
DA100 Expandable type / Subunit DS400
165
40
100 336
145
22
320 8
50
50
115
290
20
If not specified, the tolerance is
±3%. However, in cases of less than 10mm, the tolerance is
±0.3mm.
