IM DA100-01E 4
Input Modules
Check that model code given on the name plate is according to your order.
Model Codes
Model Description
DU100-11 10-channel universal input module, screw type terminal
DU100-21 20-channel universal input module, screw type terminal
DU100-31 30-channel universal input module, screw type terminal
DU100-12 10-channel universal input module, clamp type terminal
DU100-22 20-channel universal input module, clamp type terminal
DU100-32 30-channel universal input module, clamp type terminal
DU200-11 10-channel DCV/TC/DI input module, screw type terminal
DU200-21 20-channel DCV/TC/DI input module, screw type terminal
DU200-31 30-channel DCV/TC/DI input module, screw type terminal
DU200-12 10-channel DCV/TC/DI input module, clamp type terminal
DU200-22 20-channel DCV/TC/DI input module, clamp type terminal
DU200-32 30-channel DCV/TC/DI input module, clamp type terminal
DU300-11 10-channel, mA-input module with screw terminals
DU300-12 10-channel, mA-input module with clamp terminals
DU400-12 Power monitor module for single-phase use
DU400-22 Power monitor module for three-phase use
DU500-12 10-channel, strain input module with 120- Ω bridge resistors
DU500-22 10-channel, strain input module with 350-
Ω bridge resistors
DU500-32 10-channel, strain input module with NDIS terminals
DU600-11 10-channel, pulse input module with screw terminals
DU700-11 10-channel, digital input module with screw terminals
NO. (Instrument Number)
Please quote this instrument number when contacting the dealer.
I/O Terminal Modules
Check that model code given on the name plate is according to your order.
Model Codes
Model Description
DT100-11 DI/DO module, screw type terminal
DT200-11 Alarm output module (4 transfer contacts), screw type terminal
DT200-21 Alarm output module (10 make contacts), screw type terminal
DT300-11 GP-IB module
DT300-21 RS-232C module, D-sub terminal
DT300-31 RS-422-A/RS-485 module
DT300-41 Ethernet module
DT500-11 1-5 V retransmission module, screw type terminal
DT500-21 4-20 mA retransmission module, screw type terminal
NO. (Instrument Number) and Style number (equipment)
Please quote these numbers when contacting the dealer.
Checking the Contents of the Package
