3-22 IM WX201-01E
Openng Trend Settngs ndstop from a Network Host
Procedure
1. Click on the toolbar or choose Fle> Open from the menu bar. The Open
dialog box is displayed.
2. Click the Hosts on network tab. The Hosts on network tab is displayed.
3. Click the Update button. The names of hosts running DataBrowser, and their
corresponding files names and comments are displayed.
Drag to change the column width
Double-click a number to open the file
Update button
4. Select a host from the Host List. The a list of files saved on the selected host is
displayed.
5. Select a file from the list that you wish to load and click Open, or double-click the
file number. The Information dialog box opens.
6. Click the Yes button. The trend settings loaded from the trend settings file are
displayed. Click No to close the Information dialog box.
Explanaton
Host Lst
The Host List displays the names of any hosts on the network that are running
DataBrowser.
Fle Lst
Displays the settings files and comments saved on the host selected in the host list.
Host Name
Displays the name of the host selected in the host list.
Update button
Updates the host list and file list.
Fle Type, Open Button, and Cancel Button
See Opening Trend Settings Files from a Local Host.
3.7 Savng and Loadng Trend Settngs
