3-15
IM WX201-01E
Operat
on of the T
rend D
splay W
ndow
1
2
3
4
Index
Auto Zone
Displays the waveforms by dividing the waveform display area evenly according to
the number of displayed waveforms regardless of the Zone settings in the Channel
display configuration screen.
Automatically displays
the waveformin equal divisions
Active Y-axis mark
Mult-Zone
Arranges all the Y-axes from left to right, displaying all specified Y-axes. Y-axes not
selected in the Channel display configuration screen are not displayed. The display
range is set using the Zone parameter in the Channel display configuration screen.
When you drag a Y-axis button onto the Y-axis display area, the Y-axis of the relevant
channel is displayed. Conversely, if you drag a Y-axis onto the zone display area, the
Y-axis of the relevant channel is hidden.
The Y-axis of the active
channel is displayed on
the far right
Active Y-axis mark
If you drag the Y-axis display onto
the zone display area, the Y-axis is hidden
Drag the Y-axis button of the Y-axis that is
not displayed onto the Y-axis display area
to display it again
Clp Functon
Turning ON the clip function forces displayed points on the waveform that fall outside of
the scale range to revert to the max. or min. value of scale. Use the Clip button on the
toolbar to turn the clip function ON and OFF.
Clip OFF (initial setting)
Clip ON
3.4 Dsplayng Trends
