Page 54

3-18
IM WX201-01E
Normal and MnMax Format Dsplay
Values of channels In Normal format are displayed in a single row. Values of
channels in MinMax format are displayed in two rows, one for the minimum and
maximum value at the cursor position.
Swtchng the Actve Channel
You can switch the active channel. The active channel mark is displayed between the
waveform number and its color. Click the box of the channel you wish to make active.
This changes the active channel in the trend display screen as well.
Movng Cursors
You can move the cursor positions on the trend display using the Up and Down
buttons.
Note
• The cursors used to display cursor values and those used to specify the interval for
statistical computation over an area are the same.
• The Cursor Readout dialog box and opens. The Computation Results dialog box can be
displayed at the same time.
• If you click a different group in the Trend display screen with the Cursor Readout dialog box
open, the Cursor Readout dialog box displays the cursor values of the selected group.
• You can change the cursor positions in the trend display screen while the Cursor Readout
dialog box is open.
Deletng Cursors
Click the
button (Erase Cursor button) on the Trend display toolbar. The cursors are
cleared as well as the cursor values displayed in the Cursor Readout dialog box.
3.5 Dsplayng Cursor Values
