3-20 IM WX201-01E
3.7 Savng and Loadng Trend Settngs
Savng Data Trend Settngs
Procedure
1. Click (the Save button) in the DataBrowser window or choose Fle > Save
current trend configuration as from the menu bar. The Save the trend settings
dialog box appears.
Drag to change the column width
Update button
Delete button
2. Enter a file name and comment and click the Save button.
The currently displayed trend settings are saved.
Explanaton
Fle Lst
Displays the trend settings file name and comments saved on the local host.
Delete the selected fle button
Deletes the selected trend settings file.
Update button
Updates the trend settings file list.
Fle Name
Enter the name of the file you wish to save (an extension is automatically added).
Comment
Enter comments to be saved with the file. Up to 255 alphanumeric characters can be
entered.
Save button
Saves the settings file under the specified file name on the local host.
Note
After saving a trend settings file, the saved file name and comment appears in the text box the
next time you open the Save the trend settings dialog box (these items are blank if no settings
have been saved previously, or when starting up the software). Also, when you select a file in
the Save the trend settings dialog box, the file and comment are displayed in the input boxes at
the bottom of the window. This allows you to conveniently overwrite settings.
