3-16 IM WX201-01E
Trp Pont
The trip points are displayed according to the Trip 1 and Trip 2 settings in the Channel
display configuration screen. You can drag the trip 1 and trip 2 displays to change
them. These changes are reflected in the Trip 1 and Trip 2 items in the Channel display
configuration screen.
Trip 1
You can change the trip point by dragging
Trip 2
Copyng the Trend Dsplay
Clicking the XX button (copy button) in the Trend display toolbar copies the displayed
trend screen. You can paste the copied screen onto a standard “Paint”program that
comes with your operating system.
3.4 Dsplayng Trends
