Chapter 3
Operaton of the Trend Dsplay Wndow
3.1
Names of Parts n the Trend Dsplay Wndow
The Trend display window consists of the display channel settings screen and the
waveform display screen.
Openng the Trend Dsplay Wndow
Procedure
1.
Click
on the toolbar or choose Vew> Trend dsplay from the menu bar. The
Trend display window opens.
Dsplay Channel Settng Screen
The display channel setting screen can display the channel information screen, or the
channel display configure screen, each of which contain channels added from the search
results.
Channel Informaton Screen
Menu bar
Toolbar
Display Channel Setting Screen Toolbar
Display Channel Setting Screen groups toolbar
Channel Dsplay Confgure Screen
